mcr WIP PRO/V - multi-blade smoke exhaust fire damper

Key details

Damper for multi-zone fire ventilation systems

Fire resistance class: EI120(v_ew i↔o)S 1000 C₁₀₀₀₀ AAmulti

Fire resistance class: EI120(v_ed i↔o)S1000C₁₀₀₀₀AAmulti

Dampers certified for compliance with EN 12101-8.

Additional details

Certificate of constancy of performance 1396-CPR-0115.

Dampers are classified as per EN 13501-4 and tested according to EN 1366-10.

Declaration of performance 010-05-CPR-2016.

Description

mcr WIP PRO/V cut-off dampers are designed for installation in automatically-activated fire ventilation systems. They support single fire zones, as well as several zones within a single facility. They prevent propagation of fire, smoke and fire gases to the neighbouring zones. The dampers can operate in so-called mixed systems (/V-M variant).

Cut-off dampers for multi-zone fire ventilation systems, of resistance independent from direction of air flow and from installation side.

Fixed, narrow damper thickness, regardless of BxH dimensions.
